Product Details:
Payment & Shipping Terms:
|
| Key Words: | Lighting Tower Portable Diesel Generator Set | Stroke: | Four Stroke |
|---|---|---|---|
| Landuse Type Of Unit: | Low Noise, Soundproof | Alternator Insulation: | H |
| Excitation Mode: | Capacity Exciter | Protection Grade: | IP23 |
| Cooling System: | Water-cooled | Mast Height: | 8m |
| Mast Operated System: | Manual (Electric Optional) | Voltage: | 110V, 120V, 220V, 230V, 240V |
| Protection Glass: | IP33 | ||
| Highlight: | portable light towers,trailer mounted light towers |
||
GPLTY-1000*4
Light Tower Diesel Power Generator Set Ratings
| Model | GPLTY-1000*4 | |
| Rated frequency | Hz | 50 |
| Rated power | KW | 6 |
| Max. power | KW | 7 |
| Working dimension | mm | 2990x1300x8000 |
| Weight | Kg | 800 |
Relied on its high reliability, maximum safety, easy operation and simple maintenance etc., light towers are suitable for varies applications like construction site, mining filed, rental business, public equipment service, accident handling, large-scale event, disaster relief etc.
| Engine | |
| Engine brand | |
| Engine model | LD380 |
| Speed | 1500/1800 rpm |
| Prime power | 12/14.4kw |
| Cooling system | Water-cooled |
| Oil capacity | 4.5L |
| Alternator | |
| Alternator brand | |
| Alternator model | LA130/4 |
| Continued power | 7/8kVA |
| Excitation mode | Capacity exciter |
| Alternator insulation | H |
| Protection grade | IP23 |
| Mast | |
| Mast type | Manual |
| Mast height | 8m |
| Section no. (extended) | 4 |
| Mast rotation | 359° |
| Mast extension time | 45s |
| Mast descend time | 30s |
| Lighting | |
| Type of ligths | Metal halide lamp |
| Number & Power of lights | 4x1000w |
| Mast lighting & Extension | Manual operation (Electric optional) |
| Light angle turning | Manual |
| Luminous flux | 4x110000=440000 |
| Illum area (5 Lux min) | 3900m² |
| Lamps rotation | 75°(automatic) |
| Protection glass | IP33 |
| Color temperature | 4200k |
| Trailer | |
| Manufacture | |
| Braking system | / |
| Hitch | Ball type / O ring optional |
| Tire number | 2 |
| Tire rim size | 165 / 14” |
| Speed | <80km/h |
Light tower standard and optional features:
Generator set:
Mast:
Trailer:
Lighting:
Benefits:
