50Hz 3 Phase 4 Wire 470KW 588KVA Water Cooled Diesel Generator Set With IP23 Meccalte Brushless Alternator
  • name
  • name
  • name

50Hz 3 Phase 4 Wire 470KW 588KVA Water Cooled Diesel Generator Set With IP23 Meccalte Brushless Alternator

MOQ: 1set
Price: $4870-$6800
Standard Packaging: FOB, CRF,CIF,EXW…
Delivery Period: 25 working days after received down-payment
Payment Method: T/T or LC
Supply Capacity: 2,000sets/year
Detail Information
Product Description
Detail Information
Place of Origin
Jiangsu, China
Brand Name
Global Power
Certification
OEM/ISO9001
Model Number
GP C470
Key Words:
Cummins Diesel Generator Set
Output Type:
AC Three Phase
Rated Voltage::
400/230V
Prime Power (kw/kva):
470/588
Standby Power(kw/kva):
517/646
Engine Model:
Cummins, KTAA19-G6
Alternator Brand:
Meccalte, ECO40-1.5L4A
Frequency:
50Hz
Weight(kg):
4050
Dimension Size(L*W*H/mm):
3570*1550*2160
Package:
Plastic Foam Or Plywood Case
Control Module Brand:
DeepSea,Comap,Smartgen
Highlight:

588kva water cooled diesel generator set

,

50hz cummins diesel generator set

,

50hz water cooled diesel generator set

Product Description

Model: GPC470



Open Diesel Generator Set data

50Hz 3 Phase 4 Wire 470KW 588KVA Water Cooled Diesel Generator Set With IP23 Meccalte Brushless Alternator 0



Diesel Generator GPC470 (three phase)

Prime Power (kw/kva) 470/588
Standby Power (kw/kva) 517/646
Rated Voltage (V) 400/230
Voltage Recovery Time ≤1S
Rated Current (A) 847
Rated Frequency (Hz) 50
Frequency Recovery Time ≤5S
Wave Distortion ≤5%, sine wave
Running Noise db(A)/7m(Silent type) 75
Battery capacity (V-Ah) 12V 150Ah*2
Open Type-Dimension (L*W*H) (mm) 3570*1550*2160
Open Type-Weight (kg) 4050
Soundproof Type- Dimension (L*W*H) (mm) 4600*1800*2530
Soundproof Type-Weight (kg) 5850
Fuel Tank Capacity(L) 800
Continuous Running Time(hr.) 8





Cummins Engine specifications



Engine

Main features:

  1. Six-cylinder, water-cooled, in-line diesel engine
  2. Efficient fuel system for max power output and durability
  3. Large-capacity air cleaner
  4. Cost effective, fuel efficient and reliable performance
  5. Functional engine with compact structure
  6. Excellent after-sales service and sufficient spare parts supplying
  7. Easy installation and ready access for routine maintenance

50Hz 3 Phase 4 Wire 470KW 588KVA Water Cooled Diesel Generator Set With IP23 Meccalte Brushless Alternator 1

Technical data

                                                    Model KTAA19-G6

Engine brand Cummins
Output Power (kw) 470
Cylinder No. & Config. 6, in-line
Combustion System direct injection
Compression Ratio 13.5:1
Displacement (L) 19
Bore X Stroke (mm) 159*159
Engine Speed (r/min) 1500
Speed Governing Electronic
Starting System 24V DC Electric
Filter System Dry oil filter/Fuel filter/Oil filter
Cooling system Water-cooled
Coolant capacity (L) 96
Fuel Consump. (g/kw·h) 208.5
Oil Capacity (L) 50





Stamford Alternator specifications



Alternator

Main features:

  1. Advanced automatic voltage regulator (AVR) control for trouble-free operation under the most demanding conditions
  2. 2/3 pitch winding as standard, to avoid excessive neutral currents
  3. Single or two bearing construction with dynamically balanced rotor and sealed-for-life bearings
  4. Easy access for installation and maintenance
  5. IP23 as standard
  6. Self-excited control system
  7. Resist of corruption of oil and acid

50Hz 3 Phase 4 Wire 470KW 588KVA Water Cooled Diesel Generator Set With IP23 Meccalte Brushless Alternator 2

Technical data

                                                         Model ECO40-1.5L4A

Alternator brand Stamford
Rated Power (kw) 496
Excitation System Brushless, self-exciting
Voltage Regulation Mode AVR
Connection Type 3phase,4wires,”Y” connection
Pole No. 4
Rotation Speed (r/min) 1500
Temperature Rise (℃) 125
Insulation class H
Voltage Regulation (0 load) ≥95%～105%
Voltage accuracy ≤±1%
Protection Grade IP23
Telephone Influence Factor TIF＜50
Harmonic Coefficient THF＜2%









Tags:

brushless alternator generator,

brushless synchronous generator,

engine generator set
