Best Seller! Slient Diesel Generator Set with Cummins diesel engine 220kw / 275kva

Large Image : Best Seller! Slient Diesel Generator Set with Cummins diesel engine 220kw / 275kva

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Global Power
Certification:	OEM/ISO9001
Model Number:	GPC200

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	Negociable
Packaging Details:	FOB, CRF, CIF, EXW…
Delivery Time:	25 working days after received down-payment
Payment Terms:	T/T or LC
Supply Ability:	2,000sets/year

Contact Now

Detailed Product Description

Test Load:	25%, 50%, 75%, 100%, 110%	Rated Voltage:	400/230V
Standby Power(kw/kva):	220kw/275kva	China Engine Brand:	Xichai, KOFO, Weichai, YTO, Yangdong....
Alternator Brand:	Stamford,Mecc-alte, Copy Stamford,Faraday	Frequency:	50HZ / 60HZ
Genset Type:	Open,Silent, MobileTrailer..	Net Weight(kg):	1700
Dimension Size(LWH/mm):	25409501500	Control Module:	DeepSea,Comap,Smartgen
Highlight:	marine diesel genset , power generating sets

Best Seller! Slient Diesel Generator Set with Cummins diesel engine, generating sets

Technical Specifications:

Genset	Prime Power (kw/kva)		200/250
	Voltage Recovery Time		≤1S
	Rated Frequency (Hz)		50
	Frequency Recovery Time		≤5S
	Running Noise db(A)/7m(Silent type)		75
	Battery capacity (V-Ah)		12V 100Ah
Engine	Engine brand	Cummins
	Output Power (kw)	230
	Cylinder No. & Config.	4, in-line
	Combustion System	direct injection
	Engine Speed (r/min)	1500
	Speed Governing	Mechanical
	Starting System	24V DC Electric
	Filter System	Dry oil filter/Fuel filter/Oil filter
	Cooling system	Water-cooled
Alternator	Alternator brand	Stamford, Mecc-alte,Faraday…
	Excitation System	Brushless, self-exciting
	Voltage Regulation Mode	AVR
	Connection Type	3phase,4wires,”Y” connection
	Pole No.	4
	Rotation Speed (r/min)	1500
	Temperature Rise (℃)	125
	Insulation class	H
	Voltage Regulation (0 load)	≥95%～105%
	Protection Grade	IP23

Control system

Best Seller! Slient Diesel Generator Set with Cummins diesel engine 220kw / 275kva

Using microprocessor as a core, graphics LCD with big screen and backlight, key touch for operation
Security password-protected programming levels
All parameters use digital modulation, with higher reliability and stability

Built-in speed/frequency detecting units can accurately judge the states such as crank success and over speed

Power supply range is wide, accommodating to different starting battery voltage environment
Built-in watch dog can never be dead halt, ensuring smooth program execution
Modular configuration design, inserted type connection terminals, flush type installation, compact structure, easy installation

Package:
Best Seller! Slient Diesel Generator Set with Cummins diesel engine 220kw / 275kva
Global Power advantages:

1.Inspection

Each engine shall be tested at manufacturer’s workshop to certify the engine output according to present standard and fuel consumption in accordance with the site operating condition specified by purchaser on the specification datasheet.
All relevant information drawings pertinent to the testing and test procedure shall be transmitted to the purchaser in advance of the test date notification.
All accompanied documents are corresponding to the actual situation of generators, including the Qualified Certificate, Parameters and the Performance Index.

2.Guarantee

Guarantee Period: One year or 1000 running hours whichever comes first.
During the guarantee period, the spare-parts will be sent through your shipping agency in China.
Spare-parts can also be sent by air express.
24 hours service hotline is available for customers.

Our Service:

If you are interested in our products we sincerely invite you to take a visit of our factory when you are in China. We can drive to pick you up and visit our factory.
Suggest the best choice or referential suggestion based on customers’ information. Answer all questions about the product from customer.
Build customers’ profiles, follow-up service, make regular calls on customers.

Standard Supply Scope:

Generator set included: Diesel Engine, Brushless Alternator, Radiator, self-starting control panel, circuit breaker panel, Vibration damping pads, Hi-strength base frame .
Accessories Included: industrial type silencer, flexible bellow, Elbow and Flanges, Starting Battery & battery charger, Battery switch with cables
Documents included: manual book, product qualified card
