Product Details:
Payment & Shipping Terms:
|
| Power Source: | Diesel Generator | Speed: | 3000 / 3600rpm |
|---|---|---|---|
| Mast Height: | 6meter 358° Manual Operation | Excitation Mode: | AC Rotating Exciter |
| Usage: | Emergency Lighting | Cooling Method: | Water Cooling |
| Wheel Size: | 175/70r13 | Mast Operated System: | Manual Single Phase |
| Voltage: | 110V, 120V, 220V, 230V, 240V | ||
| Highlight: | portable light towers,trailer mounted light towers |
||
4×400W Metal Lamps Diesel Generator Light Tower 5Kw Waterproof Weatherproof
| Standard Equipment | |||||
| Length(mm) | 4820(3760,the tow bar be retracted) | ||||
| Width(mm) | 2850(1830,Retracted the legs) | ||||
| Height(mm) | 2920(2380,a pair of top light be detached) | ||||
| Height(Mast be extended fully) | 10050MM | ||||
| Weight (Dry,kg) | 2510 | ||||
| Engine model | 404D-22G | 404D-22G(Perkins) | |||
| Frequency(Hz) | 50 | 60 | 50 | 60 | |
| Speed(rpm) | 1500 | 1800 | 1500 | 1800 | |
| Continued Power(KVA) | 17 | 20 | 18 | 22 | |
| Number of Cylinders | 4 | 4 | |||
| Diesel Engine Characters | 4-cycle,In line, Water cooled Diesel | ||||
| Combustion Type | Indirect injection |
||||
| Engine Aspiration | Natural aspirated | ||||
| Alternator | Brushless & Single phase | ||||
| Rating Voltage(V) | 230/240V | ||||
| Alternator Insulation | Class H | ||||
| Fuel Tank | Bundled Tank | ||||
| Fuel Tank Capacity(L) | 200 | ||||
| Operating hours with full fuel | 50 hours | 52 hours | |||
| Type of Lights | Metal halide floodlight (Double ends,GEWISS or local brand) | Metal halide floodlight (Double ends,GEWISS) | |||
| Number & Power of Lights | 6*1500W | 6*2000W | |||
| Mast Lifting & Extension | Hydraulic operation | ||||
| Mast Rotation | 340°Hydraulic operation | ||||
| Light Bar Tilt | 90°Electric operation | ||||
| Stabilizing legs | Hydraulic operation | ||||
| Trailer suspension & braking system | Leaf spring & double axles with electric brakes | ||||
| Hitch & tow bar | Ball or O ring & stable hitch in stable height | ||||
| Tire & rim size | 15" | ||||
| Acoustic pressure | 70dB(A) at 7 meters away | ||||
| Output sockets | 2 Pieces (230/240V,15A) | ||||
| Mining configuration | Be fitted | ||||
| Max.quantity in a 40' container (sets) 40HQ | 3 | ||||
| Optional equipment & upgrades: | |
| Cold weather starting kit | |
| Stabilizing legs | Manually |
Options:
1) Genuine Perkins 403D-11 diesel engine
2) Genuine Yanmar diesel engine
3) Changchai CZ385Q diesel engine
4) Genuine Stamford PI044F alternator
5) 60Hz America standard lights
6) Smartgen ALC700 tower lights digital controller
7) Beacon lights
8) Extend water proof sockets
9) Flood lights (4x1000W)
