Product Details:
Payment & Shipping Terms:
|
| Power Source: | AC Power | Configuration: | Stationary,Movable Trailer |
|---|---|---|---|
| Save Energy: | Environment-Friendly | Mode: | AC Electric Motor Lubrication |
| Application: | Air Power | Drive Mode: | Electric/Diesel Available |
| Working Pressure: | 7~13bar | Export Markets:: | South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
| Highlight: | quiet air compressor,screw air compressor |
||
| Capacity/Pressure (m3/min.Mpa-1) |
3.7/0.7 | 3.6/0.8 | 3.2/1.0 | |
| Motor | Power(KW) | 22KW(30H.P) | ||
| Speed(r/min) | 2940 | |||
| Starting way | Y- starting | |||
| Volt(V) | 380 | |||
| Motor safety grade | IP54 | |||
| Motor isolation grade | F | |||
| Electrical Supply | 380V/50Hz/3Phase | |||
| Outlet Temperature(ºC) | ≤ Environment Temperature+10ºC | |||
| Driven way | Direct Driven | |||
| Noise level at 1 meter | 72+3dB(A) | |||
| Cooled method | Air cooling | |||
| Oil content | 1~3 ppm | |||
| Outlet Connection | Rc 1 | |||
| Dimension | Length(mm) | 1380 | ||
| Width(mm) | 850 | |||
| Height(mm) | 1160 | |||
| Weight(kg) | 580 | |||
Our Service:
1. If you are interested in our products we sincerely invite you to take a visit of our factory when you are in China. We can drive to pick you up and visit our factory.
2. Suggest the best choice or referential suggestion based on customers’ information. Answer all questions about the product from customer.
3. Build customers’ profiles, follow-up service, make regular calls on customers.
Company Profile:
Wuxi Global Power Technology Co., Ltd is located in national Hi-tech Nanchang district, Wuxi city, Jiangsu, China, which is famous as the ‘source of power’. Our company is a key-enterprise of being engaged in research, development, manufacture and exportation of energy-saving and environment-friendly generating sets, related parts and supporting equipment.
We mainly produced “Global Power” brand three-phase brushless synchronous alternators and many kinds of diesel generator sets, such as open generator, silent/soundproof generator, outdoor power plant, containerized gensets, trailer gensets and equipments of construction machinery like mobile light tower, forklift, air-compressor and so on.
