3 Phase Marine Generator Set 50Hz 50kw 63kVA Prime Power IP23 Protection Grade
  • name

3 Phase Marine Generator Set 50Hz 50kw 63kVA Prime Power IP23 Protection Grade

MOQ: 2 sets
Price: Negociable
Standard Packaging: Plastic Foam or Plywood Case
Delivery Period: 30-35 days after receiving the down-payment
Detail Information
Product Description
Detail Information
Place of Origin
Jiangsu, China
Brand Name
Global Power
Certification
CCS / ISO
Model Number
CCFJ100J
Type::
Micro-Computer Control Automatic Diesel Generator
Cooling System:
Sea Water Cooling
Output:
AC Three Phase
Speed:
1500prm 50Hz
Conditions Of Use:
Land Use
Excitation Mode:
Self-Excited
Export Markets:
Global
Stroke:
Four Stroke
Installation Method:
Fixed
Highlight:

3 Phase Marine Generator Set

,

50kw Marine Generator Set

,

63kVA genset generator for boats

Product Description

3 Phase Marine Generator Set 50Hz  50kw / 63kVA Prime Power IP23 Protection Grade

Main Features

Unite Power Marine diesel generator (ship's auxiliary equipment, marine generator,marine generating set, marine genset), with over 20 years of development and research, we can provide high-quality and pollution-free marine power generator to clients all over the world. The power scope is from 10kW to 800kW which can be powered by Famous marine diesel engines of Cummins, Deutz MWM, Volvo Penta, and coupled with Stamford or Marathon alternators. Until now, our marine gensets have been widely used as main power source or emergency power source of all kinds of boats, such as various kinds of large ships yards, river navigation fishing boat, transport ship, luxurious yachts and so on.



CUMMINS Marine Genset Model List :

3 Phase Marine Generator Set 50Hz 50kw 63kVA Prime Power IP23 Protection Grade 0



Specification:



1. Specification of genset
Gensets model CCFJ100J
Rated power 100KW
Rated voltage 400/230V
Rated current 180A
Rated frequency(HZ) 50
Rated speed 1500rpm
Power factor 0.8(lagging)
Dimensions(mm) (L×W×H) 2250*850*1400
Genset weight(kg) 1500
2. Specification of diesel engine
Engine brand DCEC Cummins
Engine model 6CT8.3-GM115
Number of Cylinders 6
Cylinder arrangement Vertical in-line
Cycle Four stroke
Aspiration Turbocharged
Bore×Stroke (mm×mm) 114 x 135
Displacement (Liter) 8.3
Rated power 115KW
Rated speed 1500rpm
Starting Method DC24V electrical starting
Speed Governor Electronic
Cooling System By sea water heat exchanger
Fuel Consumption 212g/kw.h
3. Specification of alternator
Alternator brand Stamford
Alternator model UCM274E/125
Number of Phase 3
Connecting Type 3 Phase and 4 Wires
Number of Bearing 1
Protection Grade IP23
Exciter Type Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class H

3 Phase Marine Generator Set 50Hz 50kw 63kVA Prime Power IP23 Protection Grade 1



 Global Power Service:



1. In manufacturing of power generators, GLOBAL POWER is able to draw on an experience

    of more than 10 years. Our total production capacity is about 20,000  units per year.
2. The power generator sets are designed for continuous power supply and have proved 10,000

    fold around the world in various applications on every continent.
3. Except standard products, we also provide customized design service for you, design generator

    sets as per your specific requirements.
4. We provide professional & in time service after sale.
