Product Details:
Payment & Shipping Terms:
|
| Rating Output: | 3500kw/437kva | Cooling Mode: | Positive Water Colling Cycle |
|---|---|---|---|
| Output Type: | AC Three Phase | Speed & Frequency: | 1500prm ,50Hz/ 18000rpm, 60HZ |
| Factor: | KVA; 0.8 Power Factor | Usage: | Standby Power Supply, Land Use |
| Excitation Mode: | AC Rotating Exciter | Engine Type: | Vertical In-line |
| Highlight: | genset silent portable,silent diesel genset |
||
Product Details:
Specification of genset | |
Gensets model | GP W350 |
Standby power | 350KW/437KVA |
Rated Voltage(V) | 400 |
Rated frequency(HZ) | 50 |
Rated Speed(RPM) | 1500 |
Power Factor | 0.8(lagging) |
Dimensions(mm) (L×W×H) | 2850x875x1509 |
Genset Weight(kg) | 1450 |
| |
Engine model | Weichai |
Standby power | 385KW |
Number of Cylinders | 6 |
Cylinder arrangement | In line |
Cycle | Four stroke |
Aspiration | Direction injectioin |
Bore×Stroke (mm×mm) | 127x 165 |
Displacement (Liter) | 12.45 |
Compression Ratio | 17:1 |
Speed Governor | Electrical Governor |
Starting Method | DC24V electrical starting |
| |
Alternator brand | Marathon |
Alternator model | MX-350-4 |
Standby power | 350kw/437kva |
Number of Phase | 3 |
Connecting Type | 3 Phase and 4 Wires |
Number of Bearing | Single |
Protection Grade | IP21 |
Altitude | ≤1000m |
Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire |
Insulation Class | H |
Telephone Influence Factor (TIF) | ≤50 |
THF | ≤2% |
Voltage Regulation, Steady State | ≤±1% |
Transient State Voltage | ≤-15%~+20% |
| Control screen | |
| Brand:Harsen/Smartgen/Deepsea | Features:English interface;LED screen;Touch buttons |
| Based Function:1.Display loading power,voltage,current,frequency,speed,temperature,oil pressure,running time,etc | |
2.Warning when low or high voltage,low or high frequency,over current,over or low speed,low or over battery voltage,etc | |
3.Over load protection,over/under frequency protection,over/under/imbalance voltage protection and low oil shutdown. | |
| The component of genset | |
| ♦Direct injection diesel engine | |
| ♦Brushless,self-excited alternator | |
| ♦Water tank | |
| ♦Circuit breaker;Standard Controlling panel | |
| ♦Base frame,include damping pad | |
| ♦Air filter;fuel ilter;oil filter;24V DC start motor | |
| ♦Battery,battery charger,battery wires,internal cables | |
| ♦Mannual books of engine,alternator,genset,control panel ,wires diagram | |
| Optional Accessories | |
| ♦Auto startup control panel | |
| ♦Automatic control panel(ATS) | |
| ♦Split type daily fuel tank;Integrated base fuel tank | |
| ♦Rainproof enclosure;Soundproof enclosure | |
| ♦Mobile power station | |
| ♦Mute power station | |
Warranty Time | |
| 12 months or 1000 hours of Warranty Time for all our products.We take the full responsibility only in the fault that created by the quality,the Wearing-parts,daily consumables and human error of operating&maintenance are not included in. | |
| Payment terms/Delivery | |
| ♦T/T,30% deposit in advance,the balance before shippment | |
| ♦Within 15 days after receving deposit | |
| The impletation of standards | |
| International Standard:ISO9001:2008 | |
| Industry Standard:GB1105/GB2820 | |
| Free services | |
| ♦Loading capacity analysis ♦Technology consulations ♦Lay out of Installation | |
| ♦Testing and Debuging ♦Training of Operation ♦Low cost spare parts | |
Photos:
Supply Scope:
Complete Cummins Marine Diesel Generator Sets including marine diesel engine, alternator, heat exchanger+water pump or radiator, standard control system, circuit breaker, absorber, filters, testing report, marine class certificate, user books and other accessories etc..
Global Power Service:
1. In manufacturing of power generators, GLOBAL POWER is able to draw on an experience
of more than 10 years. Our total production capacity is about 20,000 units per year.
2. The power generator sets are designed for continuous power supply and have proved 10,000
fold around the world in various applications on every continent.
3. Except standard products, we also provide customized design service for you, design generator
sets as per your specific requirements.
4. We provide professional & in time service after sale.
FAQ:
Q1: How is your Warranty?
Warranty: All FLYING DRAGON MERCHANDISEare warranted in accordance with our warranty terms
for a period of 12 months from date of dispatch or 1,000 running hours from date of commissioning whichever comes earlier.
Q2: Any advantages about your company?
-- Fast delivery time
-- Good design and high quality
-- Good service after sale
-- High quality with good price help you get more benefit and beat your competitors
Q3: Can you supply OEM service?
Yes, we can offer OEM service
Q4: How about the service after sale?
We have agents spread all over the world, our service network spanning more than 50 countries so we can ensure fast and good service for our clients. We are recruiting agents, welcome you to be our friend and get a win-win cooperation .
