Perkins Canopy Industrial Genset
  • name
  • name

Perkins Canopy Industrial Genset

MOQ: 1 set
Price: negotiable
Standard Packaging: plastic foam or plywood case packing
Delivery Period: 25 days after receiveing the down-payment
Supply Capacity: 2000 sets / year
Detail Information
Product Description
Detail Information
Place of Origin
Jiangsu, China
Brand Name
Global Power
Certification
OEM / ISO
Model Number
GP P21
Engine Brand::
Perkins
Engine Model:
1103A-33G
Rated Voltage (V):
400/230
Fuel Tank Capacity(L):
70
Soundproof Type- Dimension (L*W*H) (mm):
2100*950*1400
Soundproof Type-Weight (kg):
1800
Control Module Brand:
Comap,SmartGen, DeepSea
Genset Controller:
HGM410
Package:
Plastic Foam Or Plywood Case
Corlor:
Can Be Customized
Highlight:

perkins electric generator set

,

perkins industrial generator set

,

industrial electric generator set

Product Description

Perkins Canopy Industrial Genset

Basic Specification:
1. Engine brand, Perkins.
2. Alternator brand,  Marathon, Stanform, Engga...etc
3. Direct injection internal combustion engine
4. AC synchronous generator ( single bearing)
5. Cooling way, radiator with fan & water tank
6. Open type, closed type ( with sound proof canopy, trailer, container)
7. Silent / trailer diesel generator set, containerized diesel generator set, vechile mounted diesel genset.
8. Anti-vibration isolaters
9. Brushless 3 phase
10. Integral guel tank ( 8 hours)
11. sound proof, weather proof canopy is optional ( both open type and closed type can be made)
12. 50/60hz
13. Atomatic alarm system
14. Insulation, class H



Diesel Generator GPP24 (three phase)


Prime Power (kw/kva)

24/30

Standby Power (kw/kva)

26/33

Rated Voltage (V)

400/230

Voltage Recovery Time

≤1S

Rated Current (A)

43

Rated Frequency (Hz)

50

Frequency Recovery Time

≤5S

Wave Distortion

≤5%, sine wave

Running Noise db(A)/7m(Silent type)

75

Battery capacity (V-Ah)

12V 100Ah

Open Type-Dimension (L*W*H) (mm)

1500*650*1080

Open Type-Weight (kg)

750

Soundproof Type- Dimension (L*W*H) (mm)

2100*950*1400

Soundproof Type-Weight (kg)

1800

Fuel Tank Capacity(L)

70

Continuous Running Time(hr.)

8


Engine specifications


Engine
Main features:

l   Six-cylinder, water-cooled, in-line diesel engine

l   Efficient fuel system for max power output and durability

l   Large-capacity air cleaner

l   Cost effective, fuel efficient and reliable performance

l   Functional engine with compact structure

l  Excellent after-sales service and sufficient spare parts supplying
       l   Easy installation and ready access for routine maintenance

Technical data
Model                 1103A-33G

Engine brand

Perkins

Output Power (kw)

31

Cylinder No. & Config.

3, in-line

Combustion System

direct injection

Compression Ratio

19.25:1

Displacement (L)

3.3

Bore X Stroke (mm)

105*127

Engine Speed (r/min)

1500

Speed Governing

Electronic

Starting System

12V DC Electric

Filter System

Dry oil filter/Fuel filter/Oil filter

Cooling system

Water-cooled

Coolant capacity (L)

10.2

Fuel Consump. (g/kw·h)

211.1

Oil Capacity (L)

8.3


Product Picture:
Perkins Canopy Industrial Genset 0

Features and benefits


l   Tightly structure, excellent design and craft

l   Excellent cooling system, reliable performance under the harshest conditions (ambient temperature up to 40℃ and altitudes up to 1000m)

l   Self-diagnostic capability simplifies troubleshooting

l   LCD display shows system status and setup information

l   Automatic voltage regulator protects your sensitive electronics from harmonic distortion and unstable power quality

l   Soundproof type: Very quite running–75dB(A)at 23ft(7m) at normal load.

l   Enclosed muffler for added quietness

l   Service and maintenance accessible through easy-latch side service door





Tags:

Industrial Genset,

industrial power generators,

industrial diesel generators
