Product Details:
Payment & Shipping Terms:
|
| Rated Power: | 50 Kw/ 62.5kva | Cooling Mode: | Sea Water Cooling, Heat Exchager |
|---|---|---|---|
| Output: | AC Three Phase | Frequency: | 50 / 60 HZ |
| Genset Type: | Open, Silent.... | Rated Voltage: | 416/440/460/480 At 60HZ |
| Excitation Mode: | AC Rotating Exciter | Export Markets: | Global |
| Stroke: | Four Stroke | Engine: | Perkins/volvo/Weichai........ |
| Highlight: | marine diesel genset,Marine Genset |
||
Marine Genset Model List :
|
Type |
In-Line,Direct-Injection, |
|
Bore/stroke(mm) |
103/130 |
|
Displacement(L) |
4.5 |
|
Prime power/speed |
60KW/1500rpm&1800rpm |
|
Standby power(kW) |
66kw |
|
Starting method |
Electric |
|
Cooling method |
Water cooling and water tank cooling |
|
Governing method |
Electronic |
|
Aspiration method |
Natural Aspiration |
|
Fuelconsumption |
≤198 |
|
Noise @ 1m dB(A) |
≤108 |
|
Rotation direction |
Counter clockwise |
Alternator Technical Data
|
Alternator manufacturer |
Stamford |
|
Exciter type |
Single bearing, Brushless, Self-excited |
|
Rated output prime power |
50 kW |
|
Rated speed |
1500RPM /1800rpm |
|
Rated frequency |
50 Hz |
|
Phase |
3 |
|
Rated voltage |
400 V(Available with customer requirements) |
|
Power factor |
0.8 |
|
Voltage adjust range |
≥5% |
|
Voltage regulation NL-FL |
≤±1% |
|
Insulation grade |
H |
|
Protection grade |
IP23 |
Supply Scope:
Complete Cummins Marine Diesel Generator Sets including marine diesel engine, alternator, heat exchanger+water pump or radiator, standard control system, circuit breaker, absorber, filters, testing report, marine class certificate, user books and other accessories etc..
Global Power Service:
1. In manufacturing of power generators, GLOBAL POWER is able to draw on an experience
of more than 10 years. Our total production capacity is about 20,000 units per year.
2. The power generator sets are designed for continuous power supply and have proved 10,000
fold around the world in various applications on every continent.
3. Except standard products, we also provide customized design service for you, design generator
sets as per your specific requirements.
4. We provide professional & in time service after sale.
