WeiChai open frame Marine diesel generator Set 90KW/113KVA, Cummins diesel generator set for marine
  • name
  • name
  • name

WeiChai open frame Marine diesel generator Set 90KW/113KVA, Cummins diesel generator set for marine

MOQ: 2 sets
Price: Negociable
Standard Packaging: Plastic Foam or Plywood Case
Delivery Period: 30-35 days after receiving the down-payment
Detail Information
Product Description
Detail Information
Place of Origin
Jiangsu, China
Brand Name
Global Power
Certification
CCS / ISO
Model Number
CCFJ100J
Type::
Micro-Computer Control Automatic Diesel Generator
Cooling System:
Sea Water Cooling, Heat Exchager
Output Type:
AC Three Phase
Speed:
1500prm ,50Hz
Conditions Of Use:
Land Use
Usage:
Common Unit
Excitation Mode:
AC Rotating Exciter
Export Markets:
Global
Stroke:
Four Stroke
Installation Method:
Fixed
Highlight:

marine diesel engine generator set

,

marine cummins diesel generator set

,

90kw diesel engine generator set

Product Description

Features of  Cummins Marine Diesel Generator:

  • Cummins Marine Diesel Generator Sets are hot cakes in the market and used in more than 150 countries all over the world.
  • Cummins Marine Diesel Generator Sets have feasures of compact structure, full power ranging, low fuel consumptions of marine engines, low noise, reliable marine generating set performing and long life span.
  • Cummins Marine Diesel Generator Sets are originally with Cummins global warranty net, namely you can get services and spare parts easily from Cummins sales agency or service centres all over the world.
  • Can provide certificates of Marine Products, conforming to  IACS (International Association of Classification Societies)



CUMMINS Marine Genset Model List :

WeiChai open frame Marine diesel generator Set 90KW/113KVA, Cummins diesel generator set for marine 0



Specification:



1. Specification of genset
Gensets model CCFJ100J
Rated power 100KW
Rated voltage 400/230V
Rated current 180A
Rated frequency(HZ) 50
Rated speed 1500rpm
Power factor 0.8(lagging)
Dimensions(mm) (L×W×H) 2250*850*1400
Genset weight(kg) 1500
2. Specification of diesel engine
Engine brand DCEC Cummins
Engine model 6CT8.3-GM115
Number of Cylinders 6
Cylinder arrangement Vertical in-line
Cycle Four stroke
Aspiration Turbocharged
Bore×Stroke (mm×mm) 114 x 135
Displacement (Liter) 8.3
Rated power 115KW
Rated speed 1500rpm
Starting Method DC24V electrical starting
Speed Governor Electronic
Cooling System By sea water heat exchanger
Fuel Consumption 212g/kw.h
3. Specification of alternator
Alternator brand Stamford
Alternator model UCM274E/125
Number of Phase 3
Connecting Type 3 Phase and 4 Wires
Number of Bearing 1
Protection Grade IP23
Exciter Type Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class H



WeiChai open frame Marine diesel generator Set 90KW/113KVA, Cummins diesel generator set for marine 1

Supply Scope:

Complete Cummins Marine Diesel Generator Sets including marine diesel engine, alternator, heat exchanger+water pump or radiator, standard control system, circuit breaker, absorber, filters, testing report, marine class certificate, user books and other accessories etc..



 Global Power Service:



1. In manufacturing of power generators, GLOBAL POWER is able to draw on an experience

    of more than 10 years. Our total production capacity is about 20,000  units per year.
2. The power generator sets are designed for continuous power supply and have proved 10,000

    fold around the world in various applications on every continent.
3. Except standard products, we also provide customized design service for you, design generator

    sets as per your specific requirements.
4. We provide professional & in time service after sale.
