WUXI GLOBAL POWER TECHNOLOGY CO.,LTD
User First, Honesty Based; Create GP-brand by Quality, Gain reputation by Service.
|
Product Details:
Payment & Shipping Terms:
|
| Place Of Origin:: | China (Mainland) | Brand: | Deepsea |
|---|---|---|---|
| Alternator Frequency: | 50Hz / 60 Hz | Model Number:: | DSE702AS (Auto) |
| Alternator Input Range: | 15 - 305 V AC RMS (+20%) | Frequency Range: | 3.5 Hz To 75 Hz |
| Operating Temperature Range:: | -30 To +70°C | Power Supply: | 8 To 35 Vdc Continuous |
| Highlight: | generator paralleling controller,generator speed controller |
||
Diesel Generator Paralleling Controller
Specifications :
Diesel generator control panel deep sea genset controller DSE702AS (Auto) can completely replace with it. It has the function of auto mains (utility) failure control modules monitor incoming mains (utility) supplies and instruct gen-sets to start when mains (utility) power is not available. All modules include a range of intelligent control, monitoring and protection features for standard and electronic engine gen-set applications.
| Model# | DSE702AS (Auto) |
| Power Supply | 8 to 35 Vdc Continuous |
| Cranking Dropouts: | Able to survive voltage dips during cranking. Without the need for internal batteries. |
| Alternator Input Range | 15 - 305 V AC RMS (+20%) |
| Alternator Input Frequency: | 50 - 60 Hz at rated engine speed. (Minimum 75V AC) Overspeed: nominal frequency +14% (+24% Overshoot) |
| Start Output: | Solid State 1.2A negative grounding terminal |
| Run Output: | Solid State 1.2A negative grounding terminal |
| Pre-heat Output: | Solid State1.2A negative grounding terminal |
| Operating Temperature Range: | -30 to +70°C |
Key Features:
• Ultimate size to feature ratio
• Automatically transfers between mains (utility) and generator (DSE4520 only)
• Hours counter provides accurate information for monitoring and maintenance periods
• User-friendly set-up and button layout for ease of use
• Multiple parameters are monitored simultaneously which are clearly displayed on thelargest back-lit icon display inits class
• The module can be configured to suit a wide range of applications
• Uses DSE Configuration Suite PC Software for simplified configuration
• Compatible with a wide range of CAN engines
• Licence-free PC software
• IP65 rating (with optional gasket) offers increased resistance to water ingress
