90kw Marine Emergency Generator Set With Stamford Meccalte Alternator
  • name

90kw Marine Emergency Generator Set With Stamford Meccalte Alternator

MOQ: 2 sets
Price: Negociable
Standard Packaging: Plastic Foam or Plywood Case
Delivery Period: 30-35 days after receiving the down-payment
Detail Information
Product Description
Detail Information
Place of Origin
Jiangsu, China
Brand Name
Global Power
Certification
CCS / ISO
Model Number
CCF
Type::
Micro-Computer Control Automatic Diesel Generator
Cooling System:
Sea Water Cooling, Heat Exchager
Output Type:
AC Three Phase
Speed:
1500prm
Rated Power:
90kw
Usage:
Common Unit
Excitation Mode:
AC Rotating Exciter
Export Markets:
Global
Stroke:
Four Stroke
Installation Method:
Fixed
Highlight:

Marine emergency generator set

,

90kw emergency generator set

,

Three Phase emergency dg set

Product Description

90kw Marine Emergency Generator Set with Stamford / Meccalte Alternator

Features of Marine Diesel Generator:


Rated power: 90KW / 112.5kVA
Rated speed: 1500 r/min
Connecting method: 3 phase & 4 wire
Rated voltage: 415V
Rated current: 156.5A
Power factor:0.8LAG
Dimension (L× B× H): 2570*1070*1800mm
Net weight: 1500KG

  •  Marine Diesel Generator Sets are hot cakes in the market and used in more than 150 countries all over the world.
  • Cummins Marine Diesel Generator Sets have feasures of compact structure, full power ranging, low fuel consumptions of marine engines, low noise, reliable marine generating set performing and long life span.
  • Cummins Marine Diesel Generator Sets are originally with Cummins global warranty net, namely you can get services and spare parts easily from Cummins sales agency or service centres all over the world.
  • Can provide certificates of Marine Products, conforming to  IACS (International Association of Classification Societies)



CUMMINS Marine Genset Model List :

90kw Marine Emergency Generator Set With Stamford Meccalte Alternator 0



Specification:



1. Specification of genset
Rated voltage 400/230V
Rated current 180A
Rated frequency(HZ) 50
Rated speed 1500rpm
Power factor 0.8(lagging)
Dimensions(mm) (L×W×H) 2250*850*1400
Genset weight(kg) 1500
2. Specification of diesel engine
Number of Cylinders 6
Cylinder arrangement Vertical in-line
Cycle Four stroke
Aspiration Turbocharged
Bore×Stroke (mm×mm) 114 x 135
Displacement (Liter) 8.3
Rated speed 1500rpm
Starting Method DC24V electrical starting
Speed Governor Electronic
Cooling System By sea water heat exchanger
Fuel Consumption 212g/kw.h
3. Specification of alternator
Alternator brand Stamford
Number of Phase 3
Connecting Type 3 Phase and 4 Wires
Number of Bearing 1
Protection Grade IP23
Exciter Type Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class H





Supply Scope:

Complete Cummins Marine Diesel Generator Sets including marine diesel engine, alternator, heat exchanger+water pump or radiator, standard control system, circuit breaker, absorber, filters, testing report, marine class certificate, user books and other accessories etc..

90kw Marine Emergency Generator Set With Stamford Meccalte Alternator 1

 Global Power Service:



1. In manufacturing of power generators, GLOBAL POWER is able to draw on an experience

    of more than 10 years. Our total production capacity is about 20,000  units per year.
2. The power generator sets are designed for continuous power supply and have proved 10,000

    fold around the world in various applications on every continent.
3. Except standard products, we also provide customized design service for you, design generator

    sets as per your specific requirements.
4. We provide professional & in time service after sale.
