Product Details:
Payment & Shipping Terms:
|
| Prime Power: | 250KW / 313KVA | Rated Voltage: | 400V / 230V |
|---|---|---|---|
| Engine Brand: | Cummins | Engine Model: | MTA11-G3 |
| Alternator Brand: | Standford | Alternator Model: | HCI444ES |
| Connection Type: | 3phase,4wires,”Y” Connection | ||
| Highlight: | brushless synchronous generator,brushless alternator generator |
||
1. Be the result of technological research and development.
2. Detail oriented, with firmly connected parts and unique wire connection.
3. With safe and reliable system for greatly reducing low voltage, high water temperature, over speed, over / under voltage and over current.
4. Elegant appearance with compact structure.
5. Global Power Generators provide super power supply for global factories, hospitals, shopping malls, residence, field operation, marine, transportation, communications, etc.
|
Generator Data GP C250 |
Prime Power (kw/kva) | 250/313 |  |
| Standby Power (kw/kva) | 275/344 | ||
| Rated Voltage (V) | 400/230 | ||
| Voltage Recovery Time | ≤1S | ||
| Rated Current (A) | 451 | ||
| Rated Frequency (Hz) | 50 | ||
| Frequency Recovery Time | ≤5S | ||
| Wave Distortion | ≤5%, sine wave | ||
| Running Noise db(A)/7m(Silent type) | 75 | ||
| Battery capacity (V-Ah) | 12V 100Ah | ||
| Open Type-Dimension (L*W*H) (mm) | 2880*1000*1700 | ||
| Open Type-Weight (kg) | 2400 | ||
| Soundproof Type- Dimension (L*W*H) (mm) | 3950*1400*1950 | ||
| Soundproof Type-Weight (kg) | 6100 | ||
| Fuel Tank Capacity(L) | 600 | ||
| Continuous Running Time(hr.) | 8 |
|
Engine Data MTA11-G3 |
Engine brand | Cummins | |
| Output Power (kw) | 284 | ||
| Cylinder No. & Config. | 6, in-line | ||
| Combustion System | direct injection | ||
| Compression Ratio | 15.0:1 | ||
| Displacement (L) | 14 | ||
| Bore X Stroke (mm) | 125*147 | ||
| Engine Speed (r/min) | 1500 | ||
| Speed Governing | Electronic | ||
| Starting System | 24V DC Electric | ||
| Filter System | Dry oil filter/Fuel filter/Oil filter | ||
| Cooling system | Water-cooled | ||
| Coolant capacity (L) | 61 | ||
| Fuel Consump. (g/kw·h) | 188 | ||
| Oil Capacity (L) | 39 |
|
Alternator Data HCI444ES |
Alternator brand | Stamford | |
| Rated Power (kw) | 260 | ||
| Excitation System | Brushless, self-exciting | ||
| Voltage Regulation Mode | AVR | ||
| Connection Type | 3phase,4wires,”Y” connection | ||
| Pole No. | 4 | ||
| Rotation Speed (r/min) | 1500 | ||
| Temperature Rise (℃) | 125 | ||
| Insulation class | H | ||
| Voltage Regulation (0 load) | ≥95%～105% | ||
| Voltage accuracy | ≤±1% | ||
| Protection Grade | IP23 | ||
| Telephone Influence Factor | TIF＜50 | ||
| Harmonic Coefficient | THF＜2% | ||
|
Control System HGM6110 |
1.manual / auto start and protection moudle 3.New integrated controllers in manual and remote start application. 4.Featuring full gen-set monitoring and protection. 5.Powerful graphic display, Icons, symbols and bar graphs 6. High functionality set new standards in gen-set control.
|
|
|
Benefits of silent type generator
|
|
|
Company profile
Wuxi Global Power Technology CO., Ltd. have been engaged in research, development, manufacture and sales of energy-saving and environment-friendly generating sets, related parts and supporting equipment.
Our company has passed the quality management system certification of ISO9000 and environmental management system certification of ISO14000, fully certified, full compliance with industry standards at domestic and abroad.
Global power, as a strategic partner and designated OEM manufacturer of American Cummins (CUMMINS), UK Perkins (PERKINS), Volvo (VOLVO), UK Stanford (STAMFORD) in China has been keeping a steady, friendly and long-term cooperation with world leading companies.
Package and Shipment:
Product Quality Commitment
1. All products are new products, and meet the present national standard, international standard as well as the industrial standards
2. All products are manufactured according to the ISO9001 Quality Management System strictly.
3. All products are commissioned and tested strictly according to present standard.
4. All accompanied documents are corresponding to the actual situation of generators, including the Qualified Certificate, Parameters and the Performance Index.
5. All spare parts are original ones.
Service Commitment
1. Pre-sale service
Suggest the best choice or referential suggestion based on customer’s information. Offer the suggestion or service of the installation to customer if needed. Answer all questions about the product from customer.
2. Sale of service
Offer the installation index by the professionals. The training or relative files of the operation & maintenance to the customers.
3. After-sale service
Warranty time: one year or 1000 running hours, whichever comes first. Build customers’ profiles, follow-up service, make regular calls on customers.
