Product Details:
Payment & Shipping Terms:
|
| Engine Model: | GP192FE | Frequency: | 50Hz |
|---|---|---|---|
| Rated Voltage:: | 230 | Prime Power (kva): | 7.5 |
| Rated Current (A): | 32.4 | Voltage Recovery Time: | ≤1S |
| Dimension (L *W*H): | 945*565*790 | Dry Weight（kg）: | 165 |
| Max Output(kVA): | 8.25 | ||
| Highlight: | Emergency Generator Set,power generating sets |
||
GP D8000T
Ratings
| Model | GP D8000T | |
| Rated frequency | Hz | 50 |
| Rated power | KVA | 7.45 |
| Max. power | KVA | 8.25 |
| Overall dimension | mm | 945*565*790 |
| Weight | Kg | 165 |
Features and Benefits
1. Powerful Lees four-stroke engine
Lees commercial-grade OHV engines are reliable, easy-to-start and incredibly rugged.
2. Reliable and stable output
Applied the improved AVR (automatic voltage regulator), which not only can smooth the output but also provide reasonable protection against the overload of the whole set
3. Competitive economic operation
The high efficiency combustion system is designed to reduce the consumption and operation cost
4. Qualified breaker, electronic elements
Ensuring high quality of generator, protect the generator from being overload
5. Compact design
Provides unparalleled power to weight ratio
6. Large steel fuel tank
For durability and extended running time
7. Cover plate
Smart-designed cover plate effectively protects the electric elements inside
8. Fuel pump
High quality and precise fuel pump, for stable running and longer useful time
9. DC Charging
Charge the battery conveniently
10. Hardened steel tube cradle
For added durability and strength, easy transport and compact storage
11. Copper alternator
100% copper alternator ensures reliable and stable running
12. Fine craftwork
Good painting and fine craftwork, use 1.7mm thickness steel ensuring high strength
13. Wheels optional
For easily transport, now you can take the power wherever you need
Generator
| Frequency(Hz) | 50 | |
| Rated Output(kVA) | 7.45 | |
| Max Output(kVA) | 8.25 | |
| Voltage(V) | 230 | |
| Current(A) | 32.4 | |
| Configuration | Single phase | |
| Factor | 0.8-1.0 | |
| Insulation Class | B | |
| Pole | 2 | |
| Phase | 1 | |
| Excitation Mode | Self-excitation & constant voltage(AVR) | |
| Panel type | General panel | |
| output | socket | 2pc single phase socket |
| Connection Pole | Without | |
| DC12V Output | 12V 8.3A | |
| Dimension (L *W*H) | 945*565*790 | |
| Dry weight(kg) | 165 | |
| Working assorting weight (Kg) | 172 | |
| Noise level(7m)dB(A) | 72 | |
| Frame type | Silent frame | |
Engine
| Model | GP 192FE |
| Engine type | Single cylinder,4-stroke,forced air-cooled |
| Displacement(mL) | 498 |
| Cylinder NO.-bore×stroke (mm) | 1-92×75 |
| Rated power(kW) | 7.5 |
| Rated rotation speed(r/min) | 3000 |
| Fuel consumption ( g/kW.h) | 275 |
| Capacity of Fuel Tank (L) | 16 |
| Starting System | Electric starter |
| Compression ratio | 19:1 |
